ASUS ROG STRIX 1000W 80 PLUS Platinum White Edition Modular Power Supply
HomeStore

ASUS ROG STRIX 1000W 80 PLUS Platinum White Edition Modular Power Supply

ASUS ROG STRIX 1000W 80 PLUS Platinum White Edition Modular Power Supply

ASUS 1000P-GAMING Specs

Key Specs
Total Connectors
1x 20+4-Pin ATX Motherboard
2x 4+4-Pin EPS CPU
1x 16-Pin PCIe (12VHPWR)
4x 6+2-Pin PCIe
6x 15-Pin SATA
3x 6-Pin SATA / Peripheral
Show More
Cable Design
Etched
Total Wattage
1000 W
Number of +12 V Rails
1
Efficiency Rating
80 PLUS Platinum
Form Factor
ATX
Connectivity
Total Connectors
1x 20+4-Pin ATX Motherboard
2x 4+4-Pin EPS CPU
1x 16-Pin PCIe (12VHPWR)
4x 6+2-Pin PCIe
6x 15-Pin SATA
3x 6-Pin SATA / Peripheral
Cable Design
Etched
PCIe Connector Distances
29.5" / 750 mm
SATA Connector Distances
15.7" / 400 mm
20.5" / 520 mm
25.2" / 640 mm
Peripheral Connector Distances
15.7" / 400 mm
21.7" / 550 mm
27.6" / 700 mm
EPS Connector Distances
39.4" / 1000 mm
Electrical
Total Wattage
1000 W
Number of +12 V Rails
1
Combined Power for +12 V
1000 W
Max Load for +12 V
83.3 A
Combined Power for +3.3/+5 V
130 W
Max Load for +3.3 V
25 A
Max Load for +5 V
25 A
Max Power for +5 Vsb
15 W
Max Load for +5 Vsb
3 A
Max Power for -12 V
3.6 W
Max Load for -12 V
0.3 A
Input Power
100 to 240 VAC, 50 / 60 Hz
General
Efficiency Rating
80 PLUS Platinum
Active Power Factor Correction
No
Cooling
Fan Size
120 mm
Bearing Type
Ball
Noise Level
0 dBA
Physical
Form Factor
ATX
Compliance
ATX v3.1
Protection
Over-Current Protection, Over-Power Protection, Over-Temperature Protection, Over-Voltage Protection, Short-Circuit Protection, Under-Voltage Protection
Certifications
RoHS
Dimensions
6.3 x 5.9 x 3.4" / 160 x 150 x 86 mm
Weight
3.99 lb / 1.81 kg

Additional Resources

No additional resources available


All product and company names are trademarksℱ or registered¼ trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
$437.64
