Digital Arts metaSETZ TLC-4S Tally Controller for TriCaster
- 6 Assignable Tally Outputs
- Program/Preview/Talent Tally
- Intercom/Audio Pass Through
- Compatible with Most HD TriCasters
- Assign Any Output to Any Switcher Input
- Run Tally and Intercom over Single Cat5
- Connect Intercom Station to 3-Pin XLR
- Software Supports Program and Preview
- Globally Enable or Disable Talent Tally
Compatible with most HD TriCasters and all metaSETZ tally lights and relay units, the metaSETZ TLC-4S , from Digital Arts , provides 6 assignable tally outputs, Program/Preview/Talent tally, and intercom/audio pass-through. It also allows you to assign any of the 6 tally outputs to any of the switcher inputs in order to assign a tally to a network input or DDR.
The ability to run both tally and intercom over a single Cat5 cable highly sets the TLC-4S apart from a simple adapter cable. You'll be able to connect your intercom base station into the XLR port on the rear of the TLC-4S and then connect your beltpacks to the multi-purpose port on the tally lights.
Included software (provided on a flash drive) for the TriCaster supports both the red Program and green Preview tally lights, in contrast to the TLC-8D, which is limited to only one. You can also use the software to globally enable or disable the talent tally with no jumpers to change.
- Supported TriCasters
-
- TriCaster 460 or 860
- TriCaster 40, 455, 855 rev 6 software
- TriCaster 8000 rev 2-2-131031 software
| Connections | 6x tally outputs 1x 3-pin XLR |
| Supported TriCasters | TriCaster 460 or 860 TriCaster 40, 455, 855 rev 6 software TriCaster 8000 rev 2-2-131031 software |
| Power | USB port (USB cable included) |
| Packaging Info | |
|---|---|
| Package Weight | 0.75 lb |
| Box Dimensions (LxWxH) | 9.7 x 7.5 x 2.2" |
- USB Power Cable
- Flash Drive with Software for TriCaster
- Limited Lifetime Warranty
