Elation Professional Fuze Pendant Full-Spectrum 5-in-1 LED Array (230W)
HomeStore

Elation Professional Fuze Pendant Full-Spectrum 5-in-1 LED Array (230W)

Elation Professional Fuze Pendant Full-Spectrum 5-in-1 LED Array (230W)

Elation Professional Pendant Overview

Elation Professional - Fuze Pendant™
Elation Professional - Full Color Spectrum

The 230W Fuze Pendant Full-Spectrum 5-in-1 LED ArrayĀ fromĀ Elation ProfessionalĀ provides powerful illumination for a variety of house and area lighting applications. Crisp whites with a high CRI plus subtle pastels and powerful pure colors with 16-bit dimming allow for a wide range of smooth illumination and dynamic effects for any environment. At up to 11,000 lumens, the Fuze Pendant is ideal for large areas and high-ceiling applications yet compact enough to be adaptable to smaller spaces. It is convection-cooled for absolute silence and has no fans or other moving parts for a long maintenance-free product life.

The Pendant and optional yoke or recessed ceiling options provide flexibility when finding the ideal mounting position. A variety of lens choices (45° included; 25, 40, or 50° optional) allow for precise light distribution. Industry-standard power and DMX connections plus included terminal block connections for power, emergency battery input, and 0 to 10V control support multiple permanent or temporary install requirements with a single product design.

Benefits
  • Full-spectrum 230W LED array
  • 2400 to 8500K color temperature
  • CRI 90 at 3200K
  • 11,000-lumen fixture output
  • 45° lens included
  • Optional 25, 40, and 50° lenses available
  • Compact, fanless design
  • DMX, RDM, 0 to 10V, and E-FLY wireless support
  • 48V emergency battery input
  • Bare wire block terminal connections
  • Pendant bracket included
  • Optional yoke or recessed ceiling mount kits are available
  • Optional half and full snoot kits are available
UPC: 810008260869

In the Box

  • Elation Professional Fuze Pendant Full-Spectrum 5-in-1 LED Array (230W)
  • 45° Lens
  • Pendant Bracket

    Elation Professional Pendant Specs

    Source 230 W 5-in-1 RGBWL (Red, Green, Blue, White, Lime) LED Array
    Lamp Life 50,000 Hours
    Photometrics 11,000 Lumens
    Color 2400 to 8500K, CRI 90 at 3200K
    Effects Virtual Color Swatch Book
    Dimmer, RGB, RGBWL, and HSI Control Options
    Variable 16-Bit Dimming Curves
    High-Speed Electronic Shutter and Strobe
    DMX and Menu-Adjustable LED Refresh Rate Frequency
    Control 8 x DMX Channel Modes
    Standalone, Primary, and Secondary Modes
    RDM (Remote Device Management)
    0 to 10 V Dimming (Current-Sink)
    E-FLY Internal Extended Range Wireless DMX Transceiver
    4-Button Control Panel and OLED Menu Display
    Locking 5-Pin XLR Connector In/Out
    Locking IP65 Power Connector In
    3-Pin Bare Wire Terminal Block for Power
    5-Pin Bare Wire Terminal Block for 0 to 10 V, DMX
    2-Pin Bare Wire Terminal Block for 48 V Emergency Battery Input
    Electrical 100 to 240 VAC, 50/60 Hz
    Power Consumption 230 W
    Operating Temperature 14 to 113°F / -10 to 45°C
    Approvals and Ratings CE, cETLus (Pending), IP20, FCC
    Dimensions Length: 12.5" / 32 cm
    Diameter: 7.8" / 197 mm
    Weight 15.8 lb / 7.2 kg

    Elation Professional Pendant Reviews
