Erica Synths VCF Kit Overview

Modular synthesizer enthusiasts looking to learn how to build a voltage-controlled filter module from scratch will appreciate the erica synths EDU DIY VCF Module Kit, an analog low-pass filter module in Eurorack format that features a 2-pole (12 dB/oct) diode ladder circuit. This analog resonant filter offers manual and CV control of the filter cutoff and resonance.

This filter module is part of a DIY educational series that's designed to not only build a synthesizer from scratch but delves into the design and how components are chosen. The included 72-page manual takes you through the circuit-design process step-by-step, explaining every choice that was made and how it impacts the finished module. The kit includes the circuit board, electronic components, and mounting hardware. If you've ever wanted to learn how to build a synthesizer but were intimidated by the process, these educational DIY kits are your perfect solution.

Note:
erica synths will replace missing or faulty kit components, but because documentation is provided, there is no tech support or warranty. This is a DIY electronics kit and requires separately sold tools such as a soldering iron, multimeter, oscilloscope, wire cutters, etc. erica synths recommends using a breadboard to test the components BEFORE you build the module to verify that they are all functional. A Eurorack case and power supply are also required but not included.
  • 12 dB/oct (2-pole) voltage-controlled low-pass filter with resonance
  • Filter cutoff and resonance with manual and CV control and CV attenuators
  • Includes all necessary components and circuit board
  • Includes 72-page manual
  • Access to free CircuitJS, a browser-based circuit simulator

In the Box

  • Erica Synths EDU DIY VCF Eurorack Module Kit
  • Set of Electronic Components
  • Circuit Board
  • Faceplate
  • Ribbon Power Cable
  • Set of Mounting Screws

    Erica Synths VCF Kit Specs
