GVision USA K08AS-CA-0630 8.4" Class SVGA Touchscreen Commercial Monitor
GVision USA K08AS-CA Overview
The GVision USA K08AS-CA-0630 8.4" Class SVGA Touchscreen Commercial Monitor is an 8.4� kiosk solution designed for standalone use with VESA standard mounting or integration into a kiosk setup. The K08AS Offers a compact turn-key solution that can be seamlessly integrated into a wide variety of commercial settings. Applications include installing as a customer-facing display in retail environments, as a primary display for personal viewing or small-scale insets, or as a touchscreen control panel in manufacturing environments. Its durable all-metal enclosed chassis design ensures easy integration and is spill and dust-resistant.
In the Box
- GVision USA K08AS-CA-0630 8.4" Class SVGA Touchscreen Commercial Monitor
- Limited 3-Year Manufacturer Warranty
Additional Resources
No additional resources available
GVision USA K08AS-CASpecs
| Display Size |
8.4"
|
| Native Resolution |
800 x 600
|
| Maximum Brightness |
450 nits / cd/m2
|
| Touchscreen Technology |
Resistive
|
| Inputs |
1x DE-15/DB-15 (VGA)
|
| Outputs |
No
|
| Wireless |
No
|
| USB I/O |
1x USB-A (Unspecified Version) (Touchscreen Control)
|
| Ethernet I/O |
No
|
| Built-In Speakers |
No
|
| Media Card Reader |
No
|
| Display Size |
8.4"
|
| Panel Type |
TFT LCD
|
| Aspect Ratio |
4:3
|
| Display Orientation |
Landscape
|
| Native Resolution |
800 x 600
|
| Maximum Brightness |
450 nits / cd/m2
|
| HDR Support |
No
|
| Contrast Ratio |
600:1
|
| Color Support |
16.7 Million Colors (8-Bit)
|
| Viewing Angle (H x V) |
160 x 140°
|
| Screen Area |
6.7 x 5.0" / 170.4 x 127.8 mm
|
| Pixels Per Inch (ppi) |
120 ppi
|
| Touchscreen Technology |
Resistive
|
| TV Tuner |
No
|
| Inputs |
1x DE-15/DB-15 (VGA)
|
| Outputs |
No
|
| HDCP Support |
No
|
| Wireless |
No
|
| NFC |
No
|
| USB I/O |
1x USB-A (Unspecified Version) (Touchscreen Control)
|
| Ethernet I/O |
No
|
| Ambient Light Sensor |
No
|
| Multi-Input Support (PIP/PBP) |
No
|
| Built-In Speakers |
No
|
| OS Compatibility |
Windows / Linux
|
| OS Compatibility |
Windows
Linux |
| Mobile App Compatible |
No
|
| Media Card Reader |
No
|
| Built-In Mic |
No
|
| Power Consumption |
Typical: < 40.0 W
|
| Input Power |
12 VDC at 3.3 A
100 to 240 VAC, 50 / 60 Hz |
| Power Adapter Type |
External
|
| Operating Conditions |
32 to 104°F / 0 to 40°C at 10 to 90% Humidity
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C
|
| Certifications |
CE, FCC
|
| Mounting-Hole Pattern |
75 x 75 mm
|
| Material of Construction |
Metal
|
| Environmental Resistance |
Dust/Water-Resistant (Unrated)
|
| Duty Cycle |
24 Hours / 7 Days
|
| Dimensions |
8.7 x 6.5 x 1.6" / 220 x 165 x 41.8 mm
|
| Weight |
3.9 lb / 1.8 kg
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
