Harwin M20-8761042 Pin Header Vertical Wire-to-Board 2.54 mm 2 Rows 20 Contacts Surface Mount Straight M20-87

The M20-8761042 is a 20-contact 2.54mm male DIL Wired-to-board Pin Header with 100% tin over nickel plated phosphor bronze contacts, gold plated termination and black UL94V-0 polyamide (nylon) 6T housing. The M20 series connector has 3mm solder PC tails, vertical connector orientation and surface mount (SMT) connection type. It is suitable for use with 0.64mm square mating pin size. Suitable for interconnecting wired to board.

• 3A Maximum Current rating
• 250VAC/DC Voltage rating
• 20mR Maximum contact resistance
• 500MR Minimum insulation resistance
• 1000VAC Dielectric strength
• 50 operations (tin), 300 operations (gold) Durability

Applications

Commercial, Industrial

Other details

Brand	HARWIN
Part Number	M20-8761042
Quantity	Each
3D Product Image EN
Manufacturer Catalogue EN
Drawing EN
