HIROSE(HRS) HR30-6PA-6S(71) Circular Connector IP68 HR30 Series Cable Mount Plug 6 Contacts Solder Socket
HIROSE(HRS) HR30-6PA-6S(71) Circular Connector IP68 HR30 Series Cable Mount Plug 6 Contacts Solder Socket
The HR30-6PA-6S(71) is a 6-position female miniature waterproof Circular Connector with black PPS/black PBT/natural polyacetal insulator, gold plated brass/phosphor bronze contacts and stainless steel spring. The HR30 series plug has straight connector orientation, soldering wire termination method and push-pull locking style. It is recommended for use with 26AWG wire. It features an easy to operate push/pull locks, proprietary clamping method allows clamping the cable by simply tightening the cord ring. Mating portions are polarized to avoid improper mating and connector damage. It features an white index mark on them which is used to quickly align the two interface for proper mating.
- Small-size with low profile
- Waterproof construction
- Push/pull lock
- Lightweight
- Clamp structure
- Easy mating operation
- Mis-insertion prevention
- Mating mark
- 3.9mm Cable outer diameter
- 2A Rated current
- 100VAC, 140VDC Rated voltage
- 15mR Maximum contact resistance
- 1000MR Minimum insulation resistance
- 300VAC Maximum withstanding voltage
- 1000 Mating/unmating cycles
- IP68 Protection rating
Industrial
Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.Other details
| Brand | HIROSE(HRS) |
| Part Number | HR30-6PA-6S(71) |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
| CAD Multiple Formats EN | |
| Drawing EN | |
| One Page Summary EN | |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
