MULTICOMP PRO MPNPM-04VR DIP / SIP Switch, 4 Circuits, Raised Slide, Surface Mount, SPST-NO, 24 V, 25 mA
MULTICOMP PRO MPNPM-04VR DIP / SIP Switch, 4 Circuits, Raised Slide, Surface Mount, SPST-NO, 24 V, 25 mA
Product Overview
MPNPM-04VR is a SMT, 4 position, DIP switch.
- General tolerance is Ā±0.2mm, pitch is 2.54mm
- Copper (gold plated 0.075um min) contact material
- High temp thermoplastic nylon 9T UL 94V-0 (moulded black) cover/base material
- 100Mohm min insulation resistance (500VDC, 1 minute Ā±5 sec)
- Operating temperature range from -20Ā°C to +85Ā°C
- High temp thermoplastic LCP (moulded white) actuator
- Brass (gold plated 0.075um min) terminal
- 100mohm maximum (initial) contact resistance
Product details
Other details
| Brand | MULTICOMP PRO |
| Part Number | MPNPM-04VR |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
$0.73
Original: $2.45
-70%MULTICOMP PRO MPNPM-04VR DIP / SIP Switch, 4 Circuits, Raised Slide, Surface Mount, SPST-NO, 24 V, 25 mAā
$2.45
$0.73MULTICOMP PRO MPNPM-04VR DIP / SIP Switch, 4 Circuits, Raised Slide, Surface Mount, SPST-NO, 24 V, 25 mA
Product Overview
MPNPM-04VR is a SMT, 4 position, DIP switch.
- General tolerance is Ā±0.2mm, pitch is 2.54mm
- Copper (gold plated 0.075um min) contact material
- High temp thermoplastic nylon 9T UL 94V-0 (moulded black) cover/base material
- 100Mohm min insulation resistance (500VDC, 1 minute Ā±5 sec)
- Operating temperature range from -20Ā°C to +85Ā°C
- High temp thermoplastic LCP (moulded white) actuator
- Brass (gold plated 0.075um min) terminal
- 100mohm maximum (initial) contact resistance
Product details
Other details
| Brand | MULTICOMP PRO |
| Part Number | MPNPM-04VR |
| Quantity | Each |
| Technical Data Sheet EN | |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
