Omron G5RL-1E-HR DC12 G5RL-1E-HR DC12 General Purpose Relay G5RL Series Power Non Latching Spdt 12 VDC 16 A

The G5RL-1E-HR 12DC is a PCB mount Low-profile Power Relay with DC coil. This G2RL-series power relay has 1CO (SPDT) Ag alloy contact. It has high-capacity classification and PCB terminals. Creepage distance 8mm between coil and contacts.

• Single contact
• Flux protection enclosure
• 10kV Impulse withstand voltage
• High inrush model
• -40 to 85°C Operating temperature range

Applications

Consumer Electronics, Audio, Automation & Process Control, HVAC

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	OMRON
Part Number	G5RL-1E-HR DC12
Quantity	Each
Technical Data Sheet EN
