Schneider Electric LC1D80004P7 Contactor Tesys D DIN Rail 690 VAC 4PST-NO 4 Pole
The LC1D80004P7 from Schneider Electric is a TeSys D four pole contactor with normally open (NO) contacts. It is approved by UL 508, CSA C22.2, CCC, EN 60947-4-1, EN 60947-5-1, IEC 60947-4-1 and IEC 60947-5-1 standards. TeSys D contactors are designed for perfect integration in control systems. They can be used in switching equipments or relay coils, powering control equipments, powering signalling equipments and creating motor starters for any type of application.
- AC-1 utilisation category
- Rated operational voltage of 690VAC at 25Hz to 400Hz and 300VDC for power circuit
- Rated operational current of 125A at <= 440VAC (AC-1) for power circuit
- Rated impulse withstand voltage of 8KV conforming to IEC 60947
- Control circuit voltage of 230VAC at 50Hz/60Hz
- UL94 V-1 flammability
- Ambient operating temperature range from -5Ā°C to 60Ā°C
- IP2x front face degree of protection conforming to IEC 60529 standard
- Power dissipation per pole is 12.5W (AC-1)
- Rated breaking capacity of 1100A at 440V for power circuit conforming to IEC 60947 standard
Automation & Process Control, Industrial
Other details
| Brand | SCHNEIDER ELECTRIC |
| Part Number | LC1D80004P7 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Certificate of Conformity EN | |
| Safety Data Sheet B EN | |
| Enhanced Product Overview EN | |
| Manufacturer Catalogue EN | |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
