SILICON LABS XG22-EK2710A Explorer Kit, EFR32MG22E224F512IM40, IoT, ZigBee Wireless SoC
Product Overview
XG22-EK2710A is an EFR32xG22E explorer Kit. It is an ultra-low-cost, small form factor development and?evaluation platform?focused on rapid?prototyping and concept creation of?EFR32xG22E?Bluetooth LE IoT applications. The kit features a USB interface, an on-board SEGGER J-Link debugger, one?user-LED and button, and support for?hardware add-on boards via a mikroBus?socket and a Qwiic connector. The?hardware add-on support allows?developers to create and prototype?applications using a virtually endless?combination of off-the-shelf?boards from?MIKROE, SparkFun, Adafruit, and Seeed?Studios.
- Based on EFR32MG22E224F512IM40 2.4GHz Wireless SoC
- 6dBm, 512KB flash, 32KB RAM, QFN48 package
- Two LEDs and two push buttons
- Reset button
- USB connector for power and debug connection
- On-board SEGGER J-Link debugger
- Virtual COM port, Packet Trace Interface (PTI)
- Breakout pads for GPIO access and connection to external hardware
- mikroBUSļæ½ socket and QwiicĀ® connector
Product details
Other details
| Brand | SILICON LABS |
| Part Number | XG22-EK2710A |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
