TDK-LAMBDA CCG30-48-12D Isolated Through Hole DC/DC Converter, ITE, 4:1, 30 W, 2 Output, 12 V, 1.25 A
TDK-LAMBDA CCG30-48-12D Isolated Through Hole DC/DC Converter, ITE, 4:1, 30 W, 2 Output, 12 V, 1.25 A
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts
Product details
| Power Supply Applications: ITE |
| Input Ratio: 4:1 |
| Output Power Max: 30W |
| No. of Outputs: 2 Output |
| Output Voltage - Output 1: 12V |
| Output Current - Output 1: 1.25A |
| Output Voltage - Output 2: -12V |
| Output Current - Output 2: 1.25A |
| Output Regulation: - |
| Isolation Voltage: 1.5kV |
| DC / DC Converter Type: DIP |
| Input Voltage DC Nom: 48V |
| DC / DC Converter Output Type: Fixed |
| Width: 25.4mm |
| Height: 9.9mm |
| Depth: 25.4mm |
| Input Voltage DC Min: 18V |
| Input Voltage DC Max: 76V |
| Product Range: CCG Series |
Other details
| Brand | TDK-LAMBDA |
| Part Number | CCG30-48-12D |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
