Traco Power TMR 1-2423 Isolated Through Hole DC/DC Converter ITE 2:1 1 W 2 Output 15 V 33 mA

The TMR 1-2423 is a 2-output 1W board-mount isolated DC/DC Converter with regulated output, featuring wide 2:1 input voltage ranges. It offers 18 to 36VDC input voltage range and ±15VDC output voltage. An excellent efficiency allows 40 to 85°C operation temperature. Further features include remote ON/OFF control and continuous short-circuit protection. The compact dimensions and optimised design make this converter an ideal solution for many applications.

• Fully regulated outputs
• No minimum load required
• 1500VDC I/O isolation
• 80% Typical efficiency
• 24VDC Nominal input voltage

Applications

Power Management, Industrial, Sensing & Instrumentation, Communications & Networking

Other details

Brand	TRACO POWER
Part Number	TMR 1-2423
Quantity	Each
Technical Data Sheet EN
CAD Multiple Formats EN
