TRACOPOWER TEN 25-4812WI Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 18 V, 75 V, 25 W, 12 V
TRACOPOWER TEN 25-4812WI Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 18 V, 75 V, 25 W, 12 V
Product details
| Output Power Max | 25W |
| Input Voltage DC Min | 18V |
| DC / DC Converter Mounting | Through Hole |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Depth | 50.8mm |
| Width | 40.6mm |
| Product Range | TEN 25WI Series |
| DC / DC Converter Type | DIP |
| Approvals & Standards | IEC, UL |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 3 | - |
| No. of Outputs | 1 Output |
| DC / DC Converter Output Type | Fixed, Adjustable |
| Input Voltage DC Max | 75V |
| Output Current - Output 1 | 2.5A |
| Height | 9.3mm |
Other details
| Brand | TRACOPOWER |
| Part Number | TEN 25-4812WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Original: $82.51
-70%$82.51
$24.75TRACOPOWER TEN 25-4812WI Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 1 Output, 18 V, 75 V, 25 W, 12 V
