Tracopower TRN 3-0521 Isolated Board Mount DC/DC Converter 2 Output 3 W 5 V 300 mA -5
Product details
| No. of Outputs | 2 Output |
| Output Power Max | 3W |
| Output Voltage - Output 1 | 5V |
| Output Current - Output 1 | 300mA |
| Output Voltage - Output 2 | -5V |
| Output Current - Output 2 | 300mA |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | TRN 3 Series |
| Input Voltage DC Min | 4.5V |
| Input Voltage DC Max | 13.2V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | SIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | EN, IEC, UL |
| Width | 7.7mm |
| Height | 11mm |
| Depth | 11.9mm |
| RoHS Phthalates Compliant | Yes |
Other details
| Brand | TRACOPOWER |
| Part Number | TRN 3-0521 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
