XP Power JCP4024T0515 JCP4024T0515 Isolated Through Hole DC/DC Converter Metal Case ITE 2:1 40 W 3 Output 5 V 6 A

A 40W DC/DC converter with very low ripple and noise, high efficiency and continuous short circuit protection. Additional features include automatic thermal protection, remote sense, remote on/off control and input to output isolation. The six-sided metal case minimises EMC emissions and helps even dissipation of heat.

• Six-Sided Metal Case
• Undervoltage Lockout
• -40 to +100C Operating Temperature
• Remote Sense
• Remote On/Off
• 2:1 Input Range
• See Technical Note for information about XP Power's plans for the UKCA Marking

Applications

Power Management, DC, DC Converters

Other details

Brand	XP POWER
Part Number	JCP4024T0515
Quantity	Each
Technical Data Sheet EN
Technical Notes & Articles EN
Certificate of Conformity EN
