BOURNS SDR0805-471KL Surface Mount Power Inductor, SDR0805 Series, 470 µH, 340 mA, 500 mA, Unshielded, 1.96 ohm
BOURNS SDR0805-471KL Surface Mount Power Inductor, SDR0805 Series, 470 µH, 340 mA, 500 mA, Unshielded, 1.96 ohm
Product details
| Product Range | SDR0805 Series |
| Inductance | 470ĀµH |
| RMS Current (Irms) | 340mA |
| Saturation Current (Isat) | 500mA |
| Inductor Construction | Unshielded |
| DC Resistance Max | 1.96ohm |
| Power Inductor Case | 7.8mm x 7.8mm x 5.3mm |
| Inductance Tolerance | Ā± 10% |
| Packaging | Cut Tape |
Other details
| Brand | BOURNS |
| Part Number | SDR0805-471KL |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
