COILCRAFT DO3340P-223MLB Surface Mount Power Inductor, DO3340P Series, 22 µH, 2.5 A, 5.5 A, Unshielded, 0.066 ohm
COILCRAFT DO3340P-223MLB Surface Mount Power Inductor, DO3340P Series, 22 µH, 2.5 A, 5.5 A, Unshielded, 0.066 ohm
Product details
| Product Range | DO3340P Series |
| Inductance | 22ĀµH |
| RMS Current (Irms) | 2.5A |
| Saturation Current (Isat) | 5.5A |
| Inductor Construction | Unshielded |
| DC Resistance Max | 0.066ohm |
| Power Inductor Case | 12.95mm x 9.4mm x 11.43mm |
| Inductance Tolerance | Ā± 20% |
| Packaging | Cut Tape |
Other details
| Brand | COILCRAFT |
| Part Number | DO3340P-223MLB |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
