Kemet FGH0H104ZF FGH0H104ZF Supercapacitor Edlc 0.1 F 5.5 V Radial Leaded -20% +80% 5.08 mm 1000 Hours @ 70°C

The FGH0H104ZF is a Radial Leaded Supercapacitor for high energy storage applications. The FG series supercapacitors have characteristics ranging from traditional capacitor and batteries. As a result, supercapacitor can be used like a secondary battery when applied in a DC circuit. This device is best suited for use in low voltage DC hold-up applications such as embedded microprocessor systems with flash memory.

• Highly reliable against liquid leakage
• Wide range of temperature from -25°C to +70°C (FG and FGH types) and -40°C to +85°C (FGR type)
• Lead-free environmental
• 4.2V Minimum voltage holding characteristic
• Maximum current @ 30 minutes = 0.15mA

Other details

Brand	KEMET
Part Number	FGH0H104ZF
Quantity	Each
Technical Data Sheet EN
Manufacturer Catalogue EN
CAD Multiple Formats EN
