Kemet T598V157M010ATE025 Tantalum Polymer Capacitor 150 µF ± 20% 10 V 0.025 ohm 2917 [7343 Metric]

The T598 Organic Capacitor (KO-CAP) is a solid electrolytic capacitor with a conductive polymer cathode capable of delivering very low ESR and improved capacitance retention at high frequencies. KO-CAP's combines the low ESR of multilayer ceramic, the high capacitance of aluminium electrolytic and the volumetric efficiency of tantalum into a single surface mount package. Unlike liquid electrolyte-based capacitors, KO-CAP's have a very long operational life and high ripple current capabilities.

• Full compliance with AEC-Q200 Qualification Test Plan
• Qualification plan based on AEC-Q200 with 85°C/85% RH
• Subject to PPAP/PSW and Change Control
• High reliability up to 1,000 hours with 85°C/85% RH load
• Meets or exceeds EIA standard 535BAAC

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	KEMET
Part Number	T598V157M010ATE025
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
Manufacturer Catalogue EN
