Mean Well NPB-120-24AD1 NPB-120-24AD1 Battery Charger Anderson Connector Desktop Lead Acid Li-Ion 264V in 28.8 V Out New
Mean Well NPB-120-24AD1 NPB-120-24AD1 Battery Charger Anderson Connector Desktop Lead Acid Li-Ion 264V in 28.8 V Out New
NPB-120-24AD1 is a NPB-120 series charger for compatible with lead-acid (flooded, gel, AGM) and li-ion (lithium iron, lithium manganese) batteries. This product is a class I power unit (with FG), equipped with a standard IEC320-C14 AC inlet and two or three-stage charging control. Typical applications are radio system backup solution, electric scooter charger, camping car, buses, heavy duty truck, specialty vehicles, surveillance system, portable power tools.
- 90~264VAC universal AC input, built-in PFC, single output
- Charger for compatible with lead-acid and li-ion batteries
- Fanless design, wide adjustable output range, 2 or 3 stage selectable by DIP S.W
- No load power consumption is < 0.15W(AC S.W off), Anderson equivalent output connector
- Wide operating temperature range from -30ĆĀ°C to +70ĆĀ°C
- Short circuit / overvoltage /overtemperature / battery reverse polarity protection
- Comply with UL/EN62368-1 and EN60335-1/2-29 dual certification
- Front panel LED indicator for charging status, 3 years warranty
- 120W output power, 28.8V output voltage, 4A output current
- Dimension is 96mm width x 49mm height x 180mm depth
Other details
| Brand | MEAN WELL |
| Part Number | NPB-120-24AD1 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
$72.36
