SCHNEIDER ELECTRIC RXM4AB2JD General Purpose Relay, Zelio RXM Series, Power, 4PDT, 12 VDC, 6 A
SCHNEIDER ELECTRIC RXM4AB2JD General Purpose Relay, Zelio RXM Series, Power, 4PDT, 12 VDC, 6 A
- UL and CSA certified
- Switching capacity of 12A, 10A, 3A and 6A at 250VAC and 28VDC based on models
- LED (depending on version) indicating the relay status
- Four notches for rail mounting adapter or panel mounting adapter with fixing lugs
- DPDT, 3PDT, 4PDT contact configurations
- Sockets with mixed or separate contact terminals
- AC and DC coils available based on ordering
Applications
Industrial, Power Management, Automation & Process Control
Product details
| Contact Material | Silver |
| Relay Mounting | Socket |
| Coil Type | - |
| Coil Resistance | 160ohm |
| Product Range | Zelio RXM Series |
| Relay Terminals | Quick Connect |
| Contact Current | 6A |
| Approvals & Standards | CSA, IEC, UL |
| Contact Voltage VAC | 250VAC |
| Coil Voltage | 12VDC |
| Contact Configuration | 4PDT |
| Contact Voltage VDC | 250VDC |
Other details
| Brand | SCHNEIDER ELECTRIC |
| Part Number | RXM4AB2JD |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
