SENSATA/CRYDOM DRA1-CMXE100D6 Solid State Relay, SPST-NO, 6 A, 100 VDC, DIN Rail, Cage Clamp
SENSATA/CRYDOM DRA1-CMXE100D6 Solid State Relay, SPST-NO, 6 A, 100 VDC, DIN Rail, Cage Clamp
Product Overview
The DRA1-CMXE100D6 is a 10mm 1-channel DIN-rail mount Solid State Relay with cage style screw terminals for easy connection. It has thermally conductive epoxy encapsulation.
- LED status indicator
- 780? Nominal input impedance
- 2500Vrms Dielectric strength
- 10?? Minimum insulation resistance
- 15pF Input/output maximum capacitance
- -30 to 80Ā°C Operating temperature range
Applications
Industrial
Warnings
Hazard of electric shock, explosion or arc flash. Disconnect all power before installing or working with this equipment. Verify all connections and replace all covers before turning ON power.
Product details
Other details
| Brand | SENSATA/CRYDOM |
| Part Number | DRA1-CMXE100D6 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
