SENSATA/CRYDOM SSC1000-25-24 SSC1000-25-24 Solid State Relay SPST-NO 25 A 1000 VDC Panel Mount Screw DC Switch

The SSC1000-25-24 is a panel-mount Solid State Relay with IGBT output. It has redesigned housing with anti-rotation barriers. It has aluminium base plate and a current regulated nominal input impedance.

• Improved SEMS screw and washer
• DC control
• Epoxy-free design
• 3750Vrms Input/output dielectric strength
• 10â�¹R Minimum insulation resistance
• 8pF Input/output maximum capacitance
• UL94V-0 Flammability rating
• -40 to 80°C Operating temperature range

Applications

Industrial

Warnings Hazard of electric shock, explosion or arc flash. Disconnect all power before installing or working with this equipment. Verify all connections and replace all covers before turning ON power.

Product details

Contact Configuration	SPST-NO
Load Current	25A
Operating Voltage Max	1000VDC
Relay Mounting	Panel Mount
Relay Terminals	Screw
Switching Mode	DC Switch
Operating Voltage Min	0VDC
Control Voltage Min	20VDC
Control Voltage Max	28VDC
Product Range	-

Other details

Brand	SENSATA/CRYDOM
Part Number	SSC1000-25-24
Quantity	Each
Technical Data Sheet EN
Drawing EN
Product Change Notice EN
