VISHAY BFC233820335 Film Capacitor, 3.3 µF, X2, 310 V, PP (Polypropylene), ± 20%
VISHAY BFC233820335 Film Capacitor, 3.3 µF, X2, 310 V, PP (Polypropylene), ± 20%
- 7.5mm to 27.5mm lead pitch
- ±20%, ±10% and ±5% tolerance
- Rated AC voltage of 310V
- Rated DC voltage of 800V at 85°C and 630V at 110°C
- Meets IEC 60384-14-3, EN60384-14, IEC 60065, UL 60384-14, CSA-E384-14, CQC standards
- Flame retardant plastic case and epoxy resin coated with tinned wire
Applications
Industrial, Power Management, Consumer Electronics, Portable Devices
Product details
| Operating Temperature Min | -55°C |
| Voltage Rating X | 310V |
| Capacitor Terminals | Radial Leaded |
| Voltage Rating Y | - |
| Operating Temperature Max | 105°C |
| dv/dt Rating | - |
| Product Range | MKP3382 X2 Series |
| Automotive Qualification Standard | - |
| Capacitor Case Style | - |
| Suppression Class | X2 |
| Capacitance | 3.3µF |
| Capacitance Tolerance | ± 20% |
| Packaging | Each |
| Capacitor Dielectric Type | PP (Polypropylene) |
Other details
| Brand | VISHAY |
| Part Number | BFC233820335 |
| Quantity | Each |
| Technical Data Sheet EN |  |
