EPCOS B72214S2171K101 TVS Varistor, 175 V, 225 V, AdvanceD B722 Series, 455 V, Disc 14mm, Metal Oxide Varistor (MOV)
EPCOS B72214S2171K101 TVS Varistor, 175 V, 225 V, AdvanceD B722 Series, 455 V, Disc 14mm, Metal Oxide Varistor (MOV)
Product details
| Voltage Rating V AC | 175V |
| Voltage Rating V DC | 225V |
| Product Range | AdvanceD B722 Series |
| Clamping Voltage Vc Max | 455V |
| Varistor Case Style | Disc 14mm |
| Varistor Type | Metal Oxide Varistor (MOV) |
| Peak Surge Current @ 8/20Āµs | 6kA |
| Operating Temperature Min | -40Ā°C |
| Operating Temperature Max | 105Ā°C |
| Peak Energy (10/1000uS) | - |
| Automotive Qualification Standard | - |
Other details
| Brand | EPCOS |
| Part Number | B72214S2171K101 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
