LPRS YAGI-434A ANTENNA, YAGI, 7 ELEMENT, 434MHZ
- Frequency Range: 390-480MHz
- Nominal Impedance: 50 ohm
- Gain: 9dBi @ 450MHz
- VSWR: 1.5:1
- F/B Ratio: >13dB
- Maximum Input Power: 100w
- Polarization: Vertical
- Connector: SMA male
- Support Boom Material: Steel Bracket
- Element Material: Aluminium
- Number of elements: 7
- Antenna dimensions: 1000x400x70mm
- Antenna weight: 575g
- Ambient temperature: -40Ā°C to +60Ā°C
Product details
| Input Impedance | 50ohm |
| Antenna Applications | - |
| Antenna Polarisation | Vertical |
| Antenna Mounting | SMA Connector |
| VSWR | - |
| Product Range | - |
| Frequency Max | 480MHz |
| Antenna Type | Omni-directional |
| Frequency Min | 390MHz |
| Input Power | 100W |
| Gain | - |
Other details
| Brand | LPRS |
| Part Number | YAGI-434A |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
