Bourns SRN5040TA-220M Power Inductor (SMD) 22 µH 1.5 A Semishielded 1.62 SRN5040TA Series 4.95mm x 3.8mm
Bourns SRN5040TA-220M Power Inductor (SMD) 22 µH 1.5 A Semishielded 1.62 SRN5040TA Series 4.95mm x 3.8mm
Product details
| Inductance | 22ĀµH |
| RMS Current (Irms) | 1.5A |
| Inductor Construction | Semishielded |
| Saturation Current (Isat) | 1.62A |
| Product Range | SRN5040TA Series |
| Power Inductor Case | 4.95mm x 4.95mm x 3.8mm |
| DC Resistance Max | 0.123ohm |
| Inductance Tolerance | Ā± 20% |
| RoHS Phthalates Compliant | To Be Advised |
Other details
| Brand | BOURNS |
| Part Number | SRN5040TA-220M |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
