Bourns SRR1260-270M Power Inductor (SMD) 27 µH 3.6 A Shielded 3.3 SRR1260 Series 12.5mm x 6mm
Bourns SRR1260-270M Power Inductor (SMD) 27 µH 3.6 A Shielded 3.3 SRR1260 Series 12.5mm x 6mm
Product details
| Inductance | 27ĀµH |
| RMS Current (Irms) | 3.6A |
| Inductor Construction | Shielded |
| Saturation Current (Isat) | 3.3A |
| Product Range | SRR1260 Series |
| Power Inductor Case | 12.5mm x 12.5mm x 6mm |
| DC Resistance Max | 0.045ohm |
| Inductance Tolerance | Ā± 20% |
| RoHS Phthalates Compliant | To Be Advised |
Other details
| Brand | BOURNS |
| Part Number | SRR1260-270M |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bourns SRR1260-270M Power Inductor (SMD) 27 µH 3.6 A Shielded 3.3 SRR1260 Series 12.5mm x 6mm
Product details
| Inductance | 27ĀµH |
| RMS Current (Irms) | 3.6A |
| Inductor Construction | Shielded |
| Saturation Current (Isat) | 3.3A |
| Product Range | SRR1260 Series |
| Power Inductor Case | 12.5mm x 12.5mm x 6mm |
| DC Resistance Max | 0.045ohm |
| Inductance Tolerance | Ā± 20% |
| RoHS Phthalates Compliant | To Be Advised |
Other details
| Brand | BOURNS |
| Part Number | SRR1260-270M |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN | |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
