Coilcraft LPD5030V-224MRB LPD5030V-224MRB Inductor Coupled 220 µH 20% 2.625 ohm 160 mA 4.8mm x 2.9mm

The LPD5030V series Miniature Transformer with ferrite core and matte tin over nickel over silver termination. It provides tight coupling, high inductance and excellent current handling. Ideal for use in high density isolated circuit applications. It can be used as flyback transformers, coupled inductors in SEPIC applications and common mode filter chokes.

• Resistance to soldering heat
• Moisture sensitivity level 1
• PCB washing is recommended by only pure water or alcohol
• Halogen-free

Applications

Power Management, Industrial

Other details

Brand	COILCRAFT
Part Number	LPD5030V-224MRB
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
