Traco Power TXM 075-124 TXM 075-124 AC/DC Enclosed Supply (PSU) ITE 1 Outputs 75 W 24 V 3.2 A

The TXM 075-124 is a 24V/75W 1-output Enclosed Power Supply designed for a wide range of critical applications. With a low profile metal case and screw terminal block connection, it is easy to install in any equipment. This power supply has universal input and comply with European EMC standards and the low voltage directive (LVD), adjustable and fixed output voltage. Hiccup/constant power, automatic recovery overload protection mode, 105 to 150% of Vout nom overvoltage protection.

• <0.5W Up to 75W units low no load power consumption
• Withstand 300VAC surge input for 5 seconds
• No internal fan up to 150W models
• 10ms Minimum at 115VAC hold up time
• -20 to 60°C Operating temperature range

Applications

Power Management

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	TRACO POWER
Part Number	TXM 075-124
Quantity	Each
Technical Data Sheet EN
