TRACOPOWER TCL 060-124 AC/DC DIN Rail Power Supply (PSU), Industrial, 1 Output, 60 W, 24 VDC, 2.5 A
TRACOPOWER TCL 060-124 AC/DC DIN Rail Power Supply (PSU), Industrial, 1 Output, 60 W, 24 VDC, 2.5 A
The TCL series from Tracopower are DIN rail power supplies with an excellent price/performance ratio. These power supplies have tight regulated output voltage and high immunity against electrical disturbances on the mains to provide a reliable power source for sensitive loads in industrial process controls, machine tools and other equipments exposed to industrial environment. TCL series power supplies feature compact size, light weight, easy snap-on mounting on DIN-rails and choice of two connection terminal versions. These power supplies comply with all major safety standards for Europe (EN60950-1, EN50178), North America UL/cUL 60950, UL 508C listed.
- Output power range from 24W to 240W
- Maximum output current is 10A
- Switching frequency range from 55KHz to 180KHz depending on load
- Ultra compact plastic housing
- Connection by spring clamp terminals or detachable screw terminal block
- Universal input voltage range from 85VAC to 264VAC at 50Hz/60Hz
- Available with 5VDC, 12VDC, 24VDC and 48VDC output models
- Low ripple and noise
- Overload and short circuit protection
- Operating temperature range -10�C to 70�C
Applications
Power Management, Industrial
Product details
| Power Supply Output Type | Adjustable, Fixed |
| Output Power Max | 60W |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Input Voltage AC Max | 264VAC |
| Input Voltage AC Min | 85VAC |
| Product Range | TCL Series |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 24VDC |
| Output Current - Output 3 | - |
| Output Current - Output 4 | - |
| No. of Outputs | 1 Output |
| Output Voltage - Output 4 | - |
| Output Current - Output 1 | 2.5A |
Other details
| Brand | TRACOPOWER |
| Part Number | TCL 060-124 |
| Quantity | Each |
