Wurth Elektronik 74404084470 Power Inductor (SMD) 47 ?H 1.55 A Semishielded 1.9 WE-LQS Series 8mm x 4.2mm
Wurth Elektronik 74404084470 Power Inductor (SMD) 47 ?H 1.55 A Semishielded 1.9 WE-LQS Series 8mm x 4.2mm
The WE-LQS series is a compact semi-shielded power inductor which has the lowest RDC values compared to other SMD inductors in the Wurth Electronics portfolio. This compact power inductor is characterized by the robust design and the high durability. These inductor is particularly suitable for low consumption applications and may also be recommended for Energy Harvesting designs, high efficiency switching controllers and integrated DC/DC converters.
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
- Tiny Power Inductor Design
- 1.7 times more current in comparison with unshielded versions
- Robust design and large durability
- Low RDC
- Magnetically shielded with magnetic glue reducing buzz noise in ultra-low levels
- Operating temperature: -40?C to +125?C
Product details
| Inductance | 47?H |
| RMS Current (Irms) | 1.55A |
| Inductor Construction | Semishielded |
| Saturation Current (Isat) | 1.9A |
| Product Range | WE-LQS Series |
| Power Inductor Case | 8mm x 8mm x 4.2mm |
| DC Resistance Max | 0.136ohm |
| Inductance Tolerance | ? 20% |
Other details
| Brand | WURTH ELEKTRONIK |
| Part Number | 74404084470 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| Drawing EN | |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
$1.88
Wurth Elektronik 74404084470 Power Inductor (SMD) 47 ?H 1.55 A Semishielded 1.9 WE-LQS Series 8mm x 4.2mmā
$1.88
Wurth Elektronik 74404084470 Power Inductor (SMD) 47 ?H 1.55 A Semishielded 1.9 WE-LQS Series 8mm x 4.2mm
The WE-LQS series is a compact semi-shielded power inductor which has the lowest RDC values compared to other SMD inductors in the Wurth Electronics portfolio. This compact power inductor is characterized by the robust design and the high durability. These inductor is particularly suitable for low consumption applications and may also be recommended for Energy Harvesting designs, high efficiency switching controllers and integrated DC/DC converters.
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
- Tiny Power Inductor Design
- 1.7 times more current in comparison with unshielded versions
- Robust design and large durability
- Low RDC
- Magnetically shielded with magnetic glue reducing buzz noise in ultra-low levels
- Operating temperature: -40?C to +125?C
Product details
| Inductance | 47?H |
| RMS Current (Irms) | 1.55A |
| Inductor Construction | Semishielded |
| Saturation Current (Isat) | 1.9A |
| Product Range | WE-LQS Series |
| Power Inductor Case | 8mm x 8mm x 4.2mm |
| DC Resistance Max | 0.136ohm |
| Inductance Tolerance | ? 20% |
Other details
| Brand | WURTH ELEKTRONIK |
| Part Number | 74404084470 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN | |
| Drawing EN | |
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
All product and company names are trademarksā¢ or registeredĀ® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
